IP65 Outdoor Garden Energy Saving LED Sensor Solar Street /Road Lighting with Panel Sensor and Gel/ Lithium Battery

1 / 5

IP65 Outdoor Garden Energy Saving LED Sensor Solar Street /Road Lighting with Panel Sensor and Gel/ Lithium Battery

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Specifications

Light Type:

Solar

Color Temperature:

Warm White (3500-6000K)

Power:

≥30W

Illumination Time:

Charging Time:

6 Hours

IP Rating:

IP65

Voltage:

12/24V

Height:

5-15m

Material:

Aluminum Stainless Steel

Guarantee:

3-5 Years

Certification:

CE, RoHS, SGS, ISO9001

Usage:

Garden, Street, Road

Product Description

IP65 Outdoor Garden Energy Saving Integrated LED Sensor Solar Street /Road Lighting with Panel Sensor and Lithium Battery

Main Configuration	8M Pole Height 60W LED \| 11-12 Hrs 3-4 Nights Lighting
Solar Panel	140W*2PCs for 24V Lighting, Mono Crystalline Silicon, 17% Efficiency. Lifespan: 20-25 years.
Gelled Battery	150Ah/12V*2PCs, Sealed Type, Gelled. Deep cycle. Maintenance Free. Lifespan: 5-8 years.
Solar Controller	15A/24V*1PC, PWM Type. Automatic Light and Time Control. Over-charging/discharging & Reverse Protection. Lifespan: 5-10 years.
Light Source	60W*1PC LED, White Color, 140LM/W, 30Lux, 6500K. IP65, 120 Degree Angle. Lifespan: >80000Hrs.
Pole Details	8M Height, Steel, Hot-Dip Galvanized. Includes Arm, Bracket, Flange, and Fittings. Lifespan: >20 years.

Frequently Asked Questions

How many cycles can the battery handle?

At 50% discharging depth, the battery can be cycled for 1,200 times. In floating charging and discharging status, it can reach 5,000 to 6,000 cycles.

How do I choose between 12V and 24V systems?

We design systems for 12V or 24V for solar street lights, or 220-380V for normal street lights depending on the specific power requirements and pole height.

What is the difference between Mono and Poly solar panels?

The main difference lies in the production process and cost. Monosilicon offers high efficiency (17%), while Polysilicon is an older, more mature technology with different cost structures.

Does the controller support dual time control?

Yes, our solar charge controller features dual time control. You can split the 12-hour lighting period into parts, such as 6 hours of full power followed by 6 hours of half power.

What is the protection rating and durability of the system?

The system is IP65 rated, making it suitable for outdoor garden and street use. The steel poles are hot-dip galvanized for a lifespan of over 20 years.

What are the main components of the solar lighting system?

A complete system includes high-efficiency solar panels, a gelled deep-cycle battery, an intelligent PWM solar controller, a high-power LED source, and a hot-dip galvanized steel pole.
